19 Inch 2U 48Core Sliding Fiber Optic Patch Panel ODF Fixed Type

Product Name: 19 Inch 2U 48Core Sliding Fiber Optic Patch Panel ODF Fixed Type
Model NO.: YJ-0019
Origin: China
Packing: 5sets/box
Brand Name: YJ
Delivery Time: 10 Days
Minimum Order: 100 Piece/Pieces

Product Details: 19 Inch 2U 48Core Sliding Fiber Optic Patch Panel ODF Fixed Type

19 Inch 2U 48Core Sliding Fiber Optic Patch Panel

We supply 19 Inch 2U 48Core Sliding Fiber Optic Patch Panel ODF Fixed Type with very competitive prices, every single piece of Fiber Optic Frame is tested in the workshop before delivering to the customer.

Fiber cable of Fiber Optic Frame are designed and manufactured in ISO9001 registered facility.

The product range covers both single mode and multimode pigtails and pigtails which are fully qualified to RoHS standards.

Assemblies are available in all major fiber optic connector types; a range of cable color options available.

Fiber Optic Patch Panel is a 19" 2U ODF that supports direct fiber termination and pigtail splicing. The panel provides a convenient and rugged termination point for fiber optic cables in the different distributors of your cabling infrastructure.

YJ-0019 is desired with a complete closed enclosure to ensure the fibre connectivity .The splicing tray is set in chain wheel that you can pull and push easier even with fibres inside. For each tray it consists 12 cores.YJ-0019 is equipped with routing guides to limit bend radius and enhance strain-relief control. The heavy-duty metal body provides excellent protection for the inside fibers. The fiber optic panel has a metal cover with light grey powder finishing coat ,it can accept up to 24 adaptors(FC SC) that allows you to build the panels in the most flexible way. There is indication with numbers from 1 to 24 to mention the fibers.

SPECIFICATIONS:

1.   Environment temperature:-25℃~+45℃
2.   Relative humidity:≤85%(30℃)
3.   Atmosphere pressure:70~106KPa
4.   Insulated Resistance:≥2×10MΩ/500V(DC)
5.   Intensity≤15KV(DC)/1minno spark-over and no flying arc
6.   Fiber bending radium guaranteed more than 40mm:≥40mm

7. Material: Cold rolled steel

8. High quality finish,without sharp edges.

ORDERING INFORMATION:

19" Splicing Fiber Optic Patch Panel

Item NO. Description

YJ-0018              1U 24Core rack mount panel with trays.Adapter,pigtail,heat shrink sleeves are available on your requirement.
YJ-0019              2U 48Core rack mount panel with trays.Adapter,pigtail,heat shrink sleeves are available on your requirement.
YJ-0020              4U 96Core rack mount panel with trays.Adapter,pigtail,heat shrink sleeves are available on your requirement.

Why choose us?

We specialize in manufacturing all types of networking products such as cables, patch panels, jacks, plugs, faceplates, cabinets, fiber cables, patch cords, and wireless equipment. Our own brand is "YOUJET". We also act as agents of many famous companies. We have 8 automatic production lines operated by skillful workers. All of our products are produced strictly according to the ISO9001 standards.

we offer fine after-sales services. If there is any question, please feel free to contact us at any time.

Orders:

Our products are popular with North America, South America, Eastern Europe, Western Europe, Central America, Northern Europe, Southern Europe, the Middle East,Africa. And they achieved good reputation at the same time.We can also offer OEM and ODM service according to customer's requirement. Your order are welcomed!

Delivery:

In general, we deliver goods within 7-10 days after we received your payment. Meanwhile,we could provide competitive shipping terms service for you, by sea, by air or by express delivery. Of course, you can appoint another way as you like.
