19 Inch 4U 96 Core Sliding Fiber Optic Patch Panel ODF Fixed Type

Product Name: 19 Inch 4U 96 Core Sliding Fiber Optic Patch Panel ODF Fixed Type
Model NO.: YJ-0020
Origin: China
Packing: 5sets/box
Brand Name: YJ
Delivery Time: 10 Days
Minimum Order: 100 Piece/Pieces

Product Details: 19 Inch 4U 96 Core Sliding Fiber Optic Patch Panel ODF Fixed Type

19 Inch 4U 96Core Sliding Fiber Optic Patch Panel

We supply 19 Inch 4U 96 Core Sliding Fiber Optic Patch Panel ODF Fixed Type with very competitive prices, every single piece of Fixed ODF is tested in the workshop before delivering to the customer.

Fiber cable of Fixed ODF are designed and manufactured in ISO9001 registered facility.

The product range covers both single mode and multimode pigtails and pigtails which are fully qualified to RoHS standards.

Assemblies are available in all major fiber optic connector types; a range of cable color options available.

Fiber Optic Patch Panel is a 19" 4U ODF that supports direct fiber termination and pigtail splicing. The panel provides a convenient and rugged termination point for fiber optic cables in the different distributors of your cabling infrastructure.

YJ-0020 is desired with a complete closed enclosure to ensure the fibre connectivity .The splicing tray is set in chain wheel that you can pull and push easier even with fibres inside. For each tray it consists 12 cores.YJ-0020 is equipped with routing guides to limit bend radius and enhance strain-relief control. The heavy-duty metal body provides excellent protection for the inside fibers. The fiber optic panel has a metal cover with light grey powder finishing coat ,it can accept up to 24 adaptors(FC SC) that allows you to build the panels in the most flexible way. There is indication with numbers from 1 to 24 to mention the fibers.

SPECIFICATIONS:

1.   Environment temperature:-25℃~+45℃
2.   Relative humidity:≤85%(30℃)
3.   Atmosphere pressure:70~106KPa
4.   Insulated Resistance:≥2×10MΩ/500V(DC)
5.   Intensity≤15KV(DC)/1minno spark-over and no flying arc
6.   Fiber bending radium guaranteed more than 40mm:≥40mm

7. Material: Cold rolled steel

8. High quality finish,without sharp edges.

ORDERING INFORMATION:

19" Splicing Fiber Optic Patch Panel

Item NO. Description

YJ-0018 1U 24Core rack mount panel with trays.Adapter,pigtail,heat shrink sleeves are available on your requirement.

YJ-0019 2U 48Core rack mount panel with trays.Adapter,pigtail,heat shrink sleeves are available on your requirement.

YJ-0020 4U 96Core rack mount panel with trays.Adapter,pigtail,heat shrink sleeves are available on your requirement.
