0.9mm SM Fiber Optic Patch Cord , Fiber Optic Jumper with LC connector

Product Name: 0.9mm SM Fiber Optic Patch Cord , Fiber Optic Jumper with LC connector
Model NO.: YJ-011
Origin: China
Brand Name: YJ
Delivery Time: 10 Days
Minimum Order: 1 Bag
Supply Ability: 10000M/day
Quality System Certification: ISO,RHOS,UL,CE

Product Details: 0.9mm SM Fiber Optic Patch Cord , Fiber Optic Jumper with LC connector

We supply LC 0.9mm SM Fiber Optic Patch Cord , Fiber Optic Jumper with LC connector with very competitive prices, every single piece of LC 0.9mm SM Fiber Optic Patch Cord , Fiber Optic Jumper with LC connector is tested in the workshop before delivering to the customer.

Fiber cable of LC 0.9mm SM Fiber Optic Patch Cord , Fiber Optic Jumper with LC connector are designed and manufactured in ISO9001 registered facility.

The product range covers both single mode and multimode pigtails and pigtails which are fully qualified to RoHS standards.

Assemblies are available in all major fiber optic connector types; a range of cable color options available.

Quick Details :

Model Number: all models fiber optic cable

Certificate: RoHS; ISO:9001,UL

Application: Network, Telecommunications

Fiber count: Simplex, Duplex, 4~144 multi-fibers

Fiber outer diameter: 0.9mm, 1.6mm, 2.0mm, 3.0mm

Fiber type: OM1,OM2,OM3

Mode: SingldeMode, MultiMode

Insertion loss: UPC< 0.2dB, APC<0.3dB

Return loss: UPC>55dB, APC>65dB

Color: yellow,orange

Description:

Telcordia`s GR-326-Core, IEC Standard
Green Production, RoHS Standard
Excellent Polished and 100% tested.
High stability various environments
Customize order available

Applications:

Optical fiber communications system

Optical fiber access networks

Optical fiber CATV

Optical fiber test equipements

Optical fiber data communication

LAN

Specification :

Type	Standard,Master
Style	LC,SC,ST,FC.MU,DIN,D4,MPO, SC/APC,FC/APC,LC/APC.MU/APC
Fiber	Singlemode/Multimode 50/125, 62.5/125 (Multimode) OM2&OM1 50/125, 10G (Multimode) OM3
Cable	Simplex, Duplex Φ3.0mm, Φ2.0mm, Φ0.9mm PVC or LSZH
Polishing Manner	UPC,SPC,APC (8°& 6°)
Insertion Loss	≤ 0.1dB (For Singlemode Master) ≤ 0.25dB (For Singlemode Standard) ≤ 0.25dB (For Multimode) Tested by JDS RM 3750
Return Loss (Singlemode)	UPC ≥ 50dB SPC ≥ 55dB APC ≥ 60dB (typ.65dB) Tested by JDS RM3750
Repeatability	±0.1dB
Operating temperature	-400C to 850C
Geometry Requirement ( Singlemode)	Ferrule Endface Radius 7mm ≤ R ≤ 12mm (For APC) 10mm ≤ R ≤ 25mm (For Standard) Apex Offset ≤ 30 μm (For Master) Apex Offset ≤ 50 μm (For Standard) Undercut -50nm ≤ U ≤ 50nm Tested by DORC ZX-1

Competitive advantages:

Our products fiber optic cable, fiber optic patch cord,fiber optic adapter, fiber optic connector, fiber optic PLC Splitter, Fiber optic splice closure, Fiber optic patch panel, fiber optic media converter, fiber optic odf, fiber optic test equipment conform to standard of posts and telecommunications, as well as international IEC,BELLCORE standard , which are widely used on telecommunications, posts ,Electrical and Aviation. For those who has special requirement, we can also customerize the feasible proposal. We are making our efforts to be the industrial production chain base of fiber optic connector production, making our name well known all over the world . We always insists on the policy of customer first and quality first, holding the quality conception through the production process, stage by stage to control quality so as to consolidate our base.

All our products have been exported to many foreign countries like India, UAE, Germany, France, USA, Korea, Russia etc. The products are widely used in telecom, broadcast & television, power engineering, as well as some other industries . Besides,we have established close business relationship with the prestigious of telecommunication companies at home and abroad.

We wish to create better future of optical communication industry jointly with both new and existing customers.
