UPC LC to LC Single Mode Fiber Optic Patch Cord For Network , Low Insertion Loss

Fiber cable of LC/PC Patch Cord Cable Singlemode Telcordia`s GR-326-Core, IEC Standard are designed and manufactured in  ISO9001 registered facility.

The product range covers both single mode and multimode pigtails and pigtails which are fully qualified to RoHS standards.

Assemblies are available in all major fiber optic connector types; a range of cable color options available.

Quick Detail:

Telcordia`s GR-326-Core, IEC Standard

Green Production, RoHS Standard

Excellent Polished and 100% tested.

High stability various environments

Customize order available

Made in China

Description:

• Insertion Loss: PC≤0.2dB, UPC≤0.2dB, APC≤0.3dB ; Typical0.1dB;
• Return Loss: SM PC≥50dB, UPC≥55dB, APC≥65dB; MM PC≥35dB, UPC≥35dB
• Interchangeability: ≤0.2dB
• Salt Spray : ≤0.2dB
• Repeatability : (1000 times) ≤0.1dB
• Vibration: (550Hz 1.5mm) ≤0.1dB
• High Temperature : ( +85 sustain 100 hours) ≤0.2dB
• Low Temperature : (-40 sustain 100 hours) ≤0.2dB
• Temperature Circularly: (-40+85 sustain 100 hours) ≤0.2dB
• Humidity : (+25+65 93 R.H.100 hours) ≤0.2db
• Apex Offset: 0μm≤≤50μm
• Radius of Curvature: 7mm≤≤25mm
• Cable TypeSimplex, Duplex, Fan-Out;
• Connector Type: LC,SC,FC,ST, E2000, MU, MPO, MTRJ, D4,DIN, SMA, FDDI, ESCON etc.
• Fiber Mode: SM (single mode) G652D, G655, G657, MM (multimode); G651.1 (50/125, 62.5/125, 10Gb/s 50/125)

Applications:

Communication rooms

FTTH (Fiber to The Home)

LAN (Local Area Network)

FOS (fiber optic sensor)

Fiber Optic Communication System

Optical fiber connected and transmitted equipment

Defense combat readiness
