Plastic Indoor DP Box Snap Locking and Key Locking 50 pair

50pair ABS DP box with key lock wall mounted for LSA profile module

Quick Detail:

1. Can be with 5 piece 10pair module

2. Material:ABS (UL 94-0)

3. Wall mounted type,with screw fixing.

4. For LSA 10pair profile modules

5. With key and lock for secure,screw lockable way is available

6. With back mount frame to support the LSA module

Description:

The distribution block is a part of connection systems. It includes 8/10 pair connection/disconnection krone module, switching, high band modules, quick connect module, 25pair splicing module, 10pair STG module, MDF, STB module,Subscriber terminal block, back-mount frames, protection systems and other related accessories.

Small capacity for copper wire connection.It is convenient for the application mounting to walls,wood,metal or concrete poled,for networking building.It is offered under standard TIA/EIA568A/B,CE,RoHS,and ISO certificated .A widely used metal distribution box with low voltage .There is earth wire inside for protection.

It offers easy access for terminations,there is standard DIN rail for mounting the krone profile module blocks.Simple hand tools and minimum skills required for installation.Lid snaps in open position for easy access during installation .No wire stripping required. Lid may be locked to reduce the possibility of unauthorized entry .Rubber grommets at all drop wire entry and exit ports for protecting the wire from damage.All wire contacts are internal and environmentally sealed.

Applications:

For mounting to walls,wood,metal or concrete poled

Specifications :
